GC1325L-M CO2 Laser Mixer Machine for Metal Acrylic

1300*900 mm working size
Ruida controller

Feartures

1. It can be used for non-metal and thin metal material processing

2.It widely used in advertising industry,handicraft industry,toys,clothing,construction,packaging,paper,etc.
3. Applicable material:stainless steel,carbon steel,acrylic,MDF board,clothing,leather,paper,etc.

Parameters

Technical Parameters
Model	GC1325L-M
Laser type	Co2 laser
Laser power	130 / 180 / 300 / (optional)
Working area	1300x2500mm (others could be customized)
Max cutting thickness	Depends on laser power and material.
Laser optical component	II-VI lens and mirror (USA)
Laser tube	RECI or EFR glass tube
Drive	Leadshine stepper motor
Transmission	Hiwin Linear guide rail and belts transmission
Auto focus	Yes (cutting metallic materials)
Fixed laser beam optical path	Yes (5 laser mirrors and 1 lens)
Cooling way for lens & mirror	Air cooling or water cooling (optional)
Camera orientating system	Optional (this function can work in with UV printing machine, working video: https://youtu.be/zcZorfFwTPc)
Resolution ratio	0.025 mm
Min shaping character	Chinese 2mm / English Letter 1mm
Re-positioning accuracy	+/- 0.01mm
Graphic format supported	DXF DWD JPEG PCX AI TIFF PLT CDR BMP GIF
Gross power	<2500w, 220v, 50/60hz
Gross weight	900 KG
Machine dimension	316021001100mm
Package size	371022601290mm
